Quick Details

  • Type: Wrapping Machine
  • Condition: New
  • Application: Apparel, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
  • Packaging Type: Film
  • Packaging Material: PE FILM
  • Automatic Grade: Automatic
  • Driven Type: Electric
  • Voltage: V
  • Power: 43KW(for ST-ARPM-180I)
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: SUNTECH
  • Model Number: ST-ARPM
  • Dimension(L*W*H): 4000X2700X2200MM(for ST-ARPM-180I)
  • Weight: 2500KG(for ST-ARPM-180I)
  • Certification: CE, CE, ISO
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Model No: ST-ARPM-180I
  • Item Name: Factory Directly Provide textile roll wrapping machine
  • OEM: Avaliable
  • Packing Capacity: 5-7rolls/min
  • Warranty: 13 months
  • Shipping Port: Ningbo/Shanghai
  • Range of fabric width: 900-1800mm
  • Range of fabric diameter: 100-400mm
  • Maximum Fabric weight: 100kgs

Packaging & Delivery

Packaging Details Steel Pallet or Wooden Box Packing
Suntech Automatic Textile Fabric Shrink Polythene Film Packing Machine
Delivery Time Shipped in 35 days after payment
Product Description

Suntech Automatic Textile Fabric Shrink Polythene Film Packing Machine

is for packing fabric rolls in vacuum and automatic way. Packing speed up to 7 ROLLS/MIN, PLC controlled, only need one worker per unit, and material saving than traditional plastic bag.

Technical Specifications:(for standard models only)
Model
ST-ARPM-180I
ST-ARPM-180II
ST-ARPM-240I
ST-ARPM-240II
Range of Width
900-1800mm
900-1800mm
1200-2400mm
1200-2400mm
Range of Diameter
100-400mm
100-600mm
100-400mm
100-600mm
Packing Capacity
5-7rolls/min
4-6rolls/min
4-6rolls/min
3-5rolls/min
Dimensions(mm)
4180*2500*2190
4450*3220*2590
4780*2500*2190
5050*3220*2590
Weight
1500kgs
1600kgs
1600kgs
1700kgs
Power
43kw
43kw
43.5kw
43.5kw
Remark
Range of roll width can be designed & manufactured upto 3200mm.
Detailed Images
Packing

Shipped by FCL

Steel pallet + Stretching Film Packing

Shipped by LCL

Wooden Box Packing

FAQS:
Q1: What is the packing material? Can we find it in our market?
A1: It is the most common polythene film with 60-80 microns, very easy to get it in your market.

 2: What is the packing speed?
A2: Our ST-ARPM-180I can pack 300 to 420 rolls/hr, which means it can pack 2400 to 3360 rolls/eight hour.

Q3: How many Fabric Inspection Machines could link with one Packing Machine at the same time ?
A3: 10sets.

Q4: What is the electrical specs? Can I use the machine directly in my country?
A4: It is 3 Phase, 380V and 50Hz; we could make it suitable for different countries.

Q5: Is the control panel in English?
A5: Yes, it is in English.

Q6: How long is the warranty? If any problems, how to solve it?
A6: 13 months from the date of shipment. If any quality problems within warranty, Suntech will responsible for it, and send new replacements.

Q7: Will you provide free spare parts along with the machine?
A7: Yes, 5% to 10% free spare parts will be sent with the machine.

Our Clients
About Us
SUNTECH is one of the leading designers & manufacturers on textile machines for weaving & finishing units, especially for Fabric Make-up Machines and Material Storage & Handling Equipment.

Over 40 years experience, SUNTECH now has its brand office in HK and International sales office in Hangzhou. In addition, our factory is located in Ningbo city, Zhejiang, China.

Today,with more than 2500 customers and 6000 installations around the world, SUNTECH now has its agent network in Italy, Germany, Russia, Argentina, Colombia, Peru, Ecuador, Guatemala, Indonesia, Thailand, Philippines, India, Pakistan, Bangladesh, Sri Lanka, Uzbekistan, Iran,Egypt, South Africa, Syria, Mauritius, etc.
